Popular Products
5x16x45x90x8 Single Flute HSS-E Router Cutters
Our Most Popular Drainage cutter
5mm Cut 16mm Cutting Length 45mm Relief (Part of Body Reduced to Cutting width for plunging into material) 90mm Overall Length on a 8mm Shank
Typically used for Drainage slots and other smaller detail work, Most commonly used with PVC but also used with Aluminium
Single flute cutters HSS-E - stepped shank
For slotting and drilling in Aluminium- and UPVC-profiles
Used on copyrouters, drainage slot routers and CNC-machining-centres:
AFS, BJM, elumatec, Emmegi, FOM, Haffner, KABAN, Kombimatec, MLA, Pertici,
Pressta-Eisele, Rapid, Rotox, Schirmer, Striffler, TEKNA, Thorwesten, Wegoma, etc.
Speed approx. 8.000 - 20.000 rpm
Mist spray cooling spray is particularly important for aluminium working
Box Quantity Discounts on qty 5 and qty 10 Cutters
All Prices +VAT and Delivery, UK delivery Only
Made in Germany
Equivalent Ref. :76 0503, 76-0510, 76-0503, OM35283
250mm diameter TCT saw blade 32mm bore
80 Tooth
3.2 Kerf
32mm Bore
Negative Rake
Suitable for Aluminium and Plastics on Pull down Saws, Beading and General Purpose Cutting
Made In Germany
All prices plus VAT And Delivery
KPM Carpi Hex Rod 150mm Long Clamp Cylinders RJ035C0070
Will Measure Approx 190mm Long end to end with a clamp pad attached
40mm Dia
Body approx 150mm
70mm Rod Stroke
Hexagonal non Rotating Rod
M10 Male Threaded (Takes a M10 Female Clamp Pad)
1/8 Bsp Air Port
Single Acting Spring Return
Priced Per Cylinder
Clamp Pads and Air Fittings Sold Separately
Clamp Pads to Suit:
40mm dia M10 Female Rubber Clamp Pads
Commodity Code: 84123100
All Prices +VAT and Delivery
Typically used in the UPVC Window Industry to buff out / Polish scratches or bring back the surface consistency / Normal Surface look to welded areas after sanding window profile in UPVC Window Manufacture.
Comes with M8 Adapter to take Standard M8 Male Mop heads but can also be removed to take older 3/8 UNF Sisal Mop heads
Can Find uses in other plastics related industries
Spare Mop Heads Can be bought here
4500 Rpm
Quality All Metal Air Tool Body
Weight 0.91kg
4 CFM Required
1/4 BSP Air Port
Supplied with PCL Plug
Complete with Sisal Mop Head
Made to Polish / Remove Scratches in UPVC window Profile
All Prices Plus VAT and Delivery
8x40x100x8 Twin Flute Spiral HSS
8mm Cut, 40mm Cutting Length, 100mm Overall Length on a 8mm Shank
Typically used for Aluminium or PVC for General Routing Tasks
For use in Manually operated or CNC Machines
Priced Per Cutter
Product Ref. :Promac 76 0806, 76-0806
Twin Straight Flute Version Also Available
All Prices +VAT and Delivery UK Shipping Only
Special Premium Quality PTFE Self Adhesive Teflon for UPVC Welding Machines, Advanced design for long service life
Sold in 5 Metre x 1 Metre Rolls
Best Applied on a hot plate for better adhesion and to avoid bubbling
We only sell the best quality Teflon product we can source
Technical Details:
Material: PTFE Coated Glass Fabric
Coated weight:250gms/m2
Percentage of PTFE Coating:58%
Nominal Total Thickness:0.165mm
Tensiles: 1200 N/5cm
Max Temperature:+260 Deg C
Adhesive Backing: Silicone Adhesive
Peal Adhesion:9.0 N/25mm
Standard Width:1000mm
Delivery Typically 1-3 working Days on larger Items
All Prices +VAT and Delivery
Subscribe to Email News Letter and get a Free Delivery Voucher
New Subscribers to our Email Newsletter Mailing list will get a Free Delivery Voucher Code
(Limited time only, One use per customer, Free Standard UK Delivery for orders over £50, Automatically sent once you enter your email and click signup)
Router Cutters for the Window Industry and similar profile machining related industries. Drainage cutters, Trickle Vent Cutters and General Purpose routing tasks for routing slots, key holes and letterboxes etc.
New Products:
Click for more info
Pneumatic Gear Cropper
British Made gear cropper
Graule Contactor Switch
Replacement Switch part for Start / Stop Boxes on Most Graule Machines
The Contactor is the part inside the Switch Box on Graule Saws and End Millers that switches the power on and off so is often the fault if the machine will not start
Typical Symptoms of a new contactor needed are:
Machine will only keep running if you press hold the button in (Coils Gone)
Machine Will run but gets hot or runs backwards
Motor will Hum or Buzz but not fully Start
Motor Wont run at all
Coil Voltage on all machines with these contactors is 240V (Uses the Neutral), so whether your machine is Single Phase or 3 Phase like a KS for example its the same contactor
Contactor Fits: ZS200N, ZS200, ZS170N, ZS170, ZS135, AK4 End Millers, AK6 End Millers, KS Mitre Saws etc.
Colours can Vary, Some are Black some are a Terracotta Red its the Same Part
All Prices Plus VAT and Delivery
Graule EMS Cover Replacement / Emergency Stop Cover Flap
Common on Most Graule Machines, ZS170N, ZS200N, ZS135N, KS Mitre Saw, Graule AKF End Millers. Etc.
Can find uses on other machines with the same tripus start / stop box
Top is usually smashed off and only the yellow / Grey surround remains once damaged
** COLOUR MAY DIFFER DEPENDING ON STOCK**
Can be Yellow and red or Grey and Black, Identical make and dimensions
Brand: Tripus
Easy to change just 2 Screws under the cover
All Prices Plus VAT and Delivery
Graule ZS170N / ZS170 Linear Bearings set (x4 Bearings)
Genuine Graule Product from Germany
Set of 4 Bearings for a Graule ZS170N Cross Cut Saw
Replaces Bearings in the backwards / forwards cutting operation of the saw, over time they can become worn and need replacing to ensure free and easy movement
When fitting ensure the locating pin is properly aligned with the bearing
Ref: 04180202 / 09.03
Cutting and mitre circular saws type ZS 85 to ZS170N
(6-row ball bushing)
With these machines, the Kpl. Saw carriages can be removed from the guide to the front.
•Disconnect the machine from the electrical network and remove the saw blade Hang the retraction tedre (old system) or the steel cable of the rope re circulation on the carriage.
•Install the front end strip at the end of the shaft If the machine has a hydraulic feed brake, remove it as well
•Loosen the side grub screw (top or bottom) slightly on the ball socket holder so that the preload of the ball bushing is releasedCAREFULly pull the complete saw head forward from the guide shafts. Be careful not to warp the guide elements. It may be helpful if this work is carried out by 2 men. Here one man holds the weight and the other man pays attention to a straight guide when playing.Alternatively, the saw head can only be pulled forwards or backwards from the guide so far that only 2 ball bushings are released and the carriage with the other twoBall rifles are still held on the guide.Remove ball rifles from holders. To do this, turn the grease nipple back.Insert a new ball bushing and fix it with grease nipples. Pay attention to the correct installation position of the ball bushing (fixing hole). Leave the cardboard sleeve in the ball bushing!
•Gently slide onto guide shafts, pushing out the cardboard sleeve.ATTENTION: Do not warp under any circumstances, because then the ball rifles burst!!.
•Screw in the side grub screw until you feel that the ball bushing is being tensioned .As soon as the grub screw comes into pressure, only tighten slightly.ATTENTION: No large preload must be applied to the ball bushing.
ALL PRICES + VAT and Delivery
Pair of Genuine Graule ZS170N Replacement Drive belts (2 Belts are in the Machine)
Price per Belt £29.85+VAT
It is Recommended to change both belts in the machine even if only one has snapped as they will wear down differently and be slightly different sizes, Tensioner for belts is under the motor
Branding May Vary, but will be the same Genuine Graule product
For Type 135 (N) - 170 (N)
All Prices Plus VAT and Delivery
Graule ZS170N Spring Return Unit Complete with Wire Rope for easy repair
Pre-tensioned Cable makes this an easy bolt on repair to Graule ZS170N Machines with Broken return units which no longer return the saw head automatically . Just bolt on the unit to the back of the machine and bolt down the wire rope hoop to the moving head
Ref. 09.13/ 04170500 / spring installation cpl.
All Prices Plus VAT and Delivery
Replacement Saw Table for Graule ZS170N, once the table becomes too warn out and changing the insert is no longer enough its best to replace the whole table
Complete with Table Insert
Made from High Quality Ply Wood, Holes Pre Drilled for Bolt on fitment
Ref: 08.02 04126000, table, wood cpl. with insert
All Prices Plus VAT and Delivery
5x16x45x90x8 Single Flute HSS-E Router Cutters
Our Most Popular Drainage cutter
5mm Cut 16mm Cutting Length 45mm Relief (Part of Body Reduced to Cutting width for plunging into material) 90mm Overall Length on a 8mm Shank
Typically used for Drainage slots and other smaller detail work, Most commonly used with PVC but also used with Aluminium
Single flute cutters HSS-E - stepped shank
For slotting and drilling in Aluminium- and UPVC-profiles
Used on copyrouters, drainage slot routers and CNC-machining-centres:
AFS, BJM, elumatec, Emmegi, FOM, Haffner, KABAN, Kombimatec, MLA, Pertici,
Pressta-Eisele, Rapid, Rotox, Schirmer, Striffler, TEKNA, Thorwesten, Wegoma, etc.
Speed approx. 8.000 - 20.000 rpm
Mist spray cooling spray is particularly important for aluminium working
Box Quantity Discounts on qty 5 and qty 10 Cutters
All Prices +VAT and Delivery, UK delivery Only
Made in Germany
Equivalent Ref. :76 0503, 76-0510, 76-0503, OM35283
5x18x35x80x8 Single Flute HSS Router Cutters
5mm Cut 18mm Cutting Length 35mm Relief (Part of Body Reduced to Cutting width for plunging into material) 80mm Overall Length on a 8mm Shank
Typically used for Drainage slots and other smaller detail work, Most commonly used with Aluminium but also used with PVC
Single flute cutters HSS-E - stepped shank
For slotting and drilling in Aluminium- and UPVC-profiles
Used on copyrouters, drainage slot routers and CNC-machining-centres:
AFS, BJM, elumatec, Emmegi, FOM, Haffner, KABAN, Kombimatec, MLA, Pertici,
Pressta-Eisele, Rapid, Rotox, Schirmer, Striffler, TEKNA, Thorwesten, Wegoma, etc.
Speed approx. 8.000 - 20.000 rpm
Mist spray cooling spray is particularly important for aluminium working!
Equivalent Ref. :76-0501 ,OM35459
Box Quantity Discounts on 5 and 10 qty Cutters
All Prices +VAT and Delivery
Made in Germany
8x14x80x8 Single Flute HSS Router Cutters
8mm Cut 14mm Cutting Length 80mm Overall Length on a 8mm Shank
Typically used for Aluminium when only working on one face of the profile at a time
Box Quantity Discounts on 5 and 10 qty Cutters
All Prices +VAT and Delivery
Made in Germany
8x14x120x8 Single Flute HSS Router Cutters
8mm Cut 14mm Cutting Length 120mm Overall Length on a 8mm Shank
Typically used for UPVC or Ali when needing to go through the entire profile for letter boxes, key holes etc.
Probably our Most Common cutter
Box Quantity Discounts on 5 and 10 qty Cutters
All Prices +VAT and Delivery
Made in Germany
4 Most Common sizes listed please Click here for the full cutters page
** Trickle Vent Cutters for Part F Building Regulations Click Here for More info **
13mm x 40mm x 100mm x 8mm Trickle Vent Cutter Twin Flute
12mm x 40mm x 100mm x 8mm Trickle Vent Cutter Twin Flute
12mm x 28mm x 100mm x 8mm Trickle Vent Cutter Single Flute
