KPM Clamp Cylinder 40mm Dia 220mm Long

kpm carpi long stroke single acting pneumatic Clamp cylinder

KPM Hex Rod 220mm Long Clamp Cylinders RJ035L0140

KPM Saw Pneumatic Clamping Cylinder kpm carpi

KPM Clamp Cylinder 40mm Dia 220mm Long

£59.99

Quantity:

KPM Hex Rod 220mm Long Clamp Cylinders RJ035L0140

Will Measure Approx 270mm Long end to end with a clamp pad attached

40mm Dia
220mm Approx Body Length
140mm Rod Stroke
Hexagonal non Rotating Rod
M10 Male Threaded (Takes a M10 Female Clamp Pad)
1/8 Bsp Air Port
Single Acting Spring Return

Will measure approx 270mm end to end length if there is a clamp pad on

Price Per Cylinder

Clamp Pads and Air Fittings Sold Separately

Clamp Pads to Suit:

40mm dia M10 Female Rubber Clamp Pads

Commodity Code: 84123100

All Prices +VAT and Delivery

KPM Hex Rod 220mm Long Clamp Cylinders RJ035L0140

Will Measure Approx 270mm Long end to end with a clamp pad attached

40mm Dia
220mm Approx Body Length
140mm Rod Stroke
Hexagonal non Rotating Rod
M10 Male Threaded (Takes a M10 Female Clamp Pad)
1/8 Bsp Air Port
Single Acting Spring Return

Will measure approx 270mm end to end length if there is a clamp pad on

Price Per Cylinder

Clamp Pads and Air Fittings Sold Separately

Clamp Pads to Suit:

40mm dia M10 Female Rubber Clamp Pads

Commodity Code: 84123100

All Prices +VAT and Delivery
